Universal remote control duplicator
Universal RF remote control duplicator is capable of copying most fixed code or learning code RF remote controls face to face, and can be used in many circumstances, such as cars, gates, garage door openers, barriers, home security systems, etc. so you will always have a backup remote control. A typical remote control duplicator / self-learning copy remote is operating at 433.92MHz / 315MHz frequency, which is commonly used by garage door opener manufacturers. But please note that the frequency band 286MHz to 400MHz can't be used in the EU. It's very useful to duplicate original remote transmitters to reduce costs, despite the potentials, a self-learning remote control duplicator is less expensive than original devices, and also permits to integrate several different remotes (both operating at the same frequency, such as 433.92MHz) into one single transmitter. so it is also very convenient.
Key specifications
- Prevents loss and replaces old remote controls
- Self learning remote control
- Used in car alarms, home alarms, panic buttons, garage door, rolling curtain, and more
- Copies most radio frequency fixed code remote controls
- Learning face to face in seconds
- Battery included
- Coding mode: fixed code or learning code
- Frequency: 433.92MHz / 315MHz
- Battery model: 27A
- Voltage: 12V
- Chip of fixed code type: PT2240, PT2260, PT2262, EV1527, FP527, AX5326, PT2262, PT2242, HT600, HT680, HT6207, T6010, HT6012, HT6014, AX5326-4, SMC5026, SMC5326-3, SMC5326-4, SMC918, SMC918-3, and SMC918-4
Encoder IC Compatibility List
- 2260
- 2262
- 2264
- FP527
- HT12D
- HT12E
- PT2240
- PT2242
- EV1527
- HT6010 / HT6013 / HT6014
- HT600 / HT680 / HT6207 / HT6010 / HT6012
- MC145026 / HT640
- 5026-1 / 5026-2 / 5026-3 / 5026-4
- SMC918
- AX5326-3 / AX5326-4
- AX5026
